Açıklama
| MODEL NO | OPAX-2210W | |
| BASIC PARAMETER | ||
| Image Sensor | 5 MP 1/2.9″ Sensor (SSC30KD) | |
| Chipset | (SSC30KD+SC4653) | |
| Effective Pixels | 5MP | |
| Min. Illumination | Color: 0Lux (Warm light on) | |
| Warm Light | 3 WARM LIGHT | |
| Lens | 5MP LENS M12 3.6mm F1.2 fixed lens | |
| Noise Reduction | 3D digital noise reduction | |
| WDR | Support WDR , >80db | |
| BLC | Support | |
| DEFOGGING | Support | |
| Forced-Anti Flicker | Support | |
| Horizontal and Vertical Flip |
Support | |
| Day Shutter Mode | Auto And Manual (1/10-1/10000 ) | |
| Night Shutter Mode | Auto And Manual (1/10-1/10000 ) | |
| Compression | H.264, H.265, H.265+ | |
| Light Mode | Warm Light / Infrared and warm Light/ Infrared 3 model support | |
| Light Sensitivity | 1-100 | |
| Led Control Mode Auto and Manual | ||
| Led Brightness | 0- 1000 | |
| Light on illumination | 0,01-1.5 arasında ayarlanabilir | |
| P2P | P2P uzaktan NVR olmadan izleme imkanı mevcut olup, Danale programı ile 64 kameraya kadar Kayıt cihazı olmadanda izleyebilirsiniz. | |
| S/N Ratio | ≥50db(AGC closed) | |
| Image Settings | Support for brightness, contrast, saturation, white balance, AWB (automatic white balance), AGC (automatic gain), AE (automatic exposure); support privacy area; normal / 90° / 270° image rotation; Automatic, manual color to black and other switches | |
| OSD | Support OSD setting, drag the position freely | |
| Privacy Mask | Support 4 Zone | |
| AUDIO / VIDEO ENCODING | ||
| Encoding Format | H.265+ Main Profile Encoding; H.264 Baseline / Main Profile / High Profile Encoding | |
| Image Resolution | Main Stream | 2880X16620 (15FPS) ,2560X1440 (30 Fps) ,2304×1296 (30fps) ,1920×1080 ,720P |
| Sub Stream | D1(704*576) /VGA, 360P(640*360 ) / CIF(352*288) | |
| Frame rate | 5MP(15fps 50HZ/60Hz), 4MP(30fps 50HZ/60Hz) FULL 30 FPS | |
| Video Bit Rate | 32Kbps-3Mbps continuously adjustable, support CBR / VBR | |
| Overlay | Channel name, date time, steam info; position is adjustable. | |
| DATA TRANSMISSION & STORAGE | ||
| Data Storage | Video, Image | |
| Storage | Manual, automatic (cycle, timing, alarm switch, motion detection) | |
| Alarm Data | FTP, E-mail, Browser, Management software | |
| Protocol | HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search(Support P6S IP camera, DVR, NVS and etc.) | |
| Access Standard | ONVIF SDK | |
| Access protocol | Support ONVIF/private protocol/CGI | |
| Client Browse | Support IE9.0 and above browser, support 4 users concurrent access (MAX) | |
| PORT | ||
| Network | RJ45, 10M/100M network adaptive | |
| Wifi | NO | |
| AUDIO | ||
| Audio | NOT SUPPORT | |
| Input | 1CH In | |
| Output | 1CH oUT | |
| GENERAL | ||
| Operation T/H | -20°C ~ 65°C / 0% – 90% | |
| Waterproof | NO | |
| Power Supply | DC12V 2A | |
| Power Consumption | <10W | |
